Very little effort should be required to accomplish this. Align the pins on the male cable with the sockets on the female cable and gently couple them. Note that there is only one proper way for the cables to fit together. Holding one of the V.35 ends in each hand, examine the pins and sockets as well as the threaded connectors. The DTE and DCE V.35 cables must be joined. The cables are also labeled as DCE or DTE on the router end of the cable. The V.35 DCE connector is usually a female V.35 (34-pin) connector.
The labs will use one V.35 DCE cable and one V.35 DTE cable to simulate the WAN con-nection.
Tera term in packet tracer serial#
The DCE-DTE connection between routers is referred to as a null serial cable. In the academy labs, the WAN connection between routers uses one DCE cable and one DTE cable. Create a null serial cable to connect the R1 router to the R2 router The connection from one router serial interface to another router serial interface simulates the entire WAN cloud. In the academy labs, devices that make up the WAN cloud are simulated by the connection between the back-to-back DTE-DCE cables. An administrator located in Sydney would have to connect to the router in New York through the WAN cloud to troubleshoot the New York router. In a real-world situation, one router might be in New York, while another router might be in Sydney, Australia. Unlike the cables in the academy lab setup, the serial cables in the real world are not connected back to back. This device is used to convert the data from the DTE into a form acceptable to the WAN service provider. This equipment is connected to the service provider through a data communications equipment (DCE) device, which is commonly a modem or channel service unit (CSU)/data service unit (DSU). In a real-world WAN connection, the customer premises equipment (CPE), which is often a router, is the data terminal equipment (DTE). Task 2: Cable the Serial Link Between the R1 and R2 Routers Cours introduction to Routing and Packet Forwarding, tutoriel & guide de travaux pratiques en pdf.
